Hugong EMIG 200LED

The EMIG 200 LED is a portable 3-in-1 multi-process inverter welder featuring new generation Advanced IGBT Inverter Technology for superior performance and reliability.

Designed for both workshop and on-site applications, it delivers precise, stable arcs across a variety of welding processes.

Key Features:
Multi-Process Capability: MIG (GMAW), MMA (SMAW), and Lift TIG (GTAW) welding modes.
Advanced IGBT Inverter Technology:
Ensures high efficiency, consistent output, and excellent weld quality.
HD Vision LED Display:
Provides clear visibility with waveform technology for precise control and monitoring.

Excellent Metal Compatibility:
Suitable for steel, stainless steel, aluminium, and flux-cored wires.

User-Friendly Design:
- Step-less adjustment of wire feeding speed (A), voltage (V), and arc force.
- 2T/4T function for continuous or trigger-controlled welding.
- European-type quick connectors for easy and secure cable changes.

Built-In MMA Enhancements:
Anti-sticking, hot start, and adjustable arc force features for smooth electrode ignition and reduced spatter.

Protection & Cooling:
IP21S protection class for electrical safety.
Fan-cooled system for extended duty cycles and stable operation.

Voltage Protection:
Integrated over/under voltage safeguards for reliable performance in variable power conditions.

Technical Highlights:
Input Power: 230
Output Current Range: MIG 20-200
MMA 30-170 Tig 15-200

Duty Cycle: 40% @ 200
Weight: 15kg

Applications:
Ideal for light fabrication, maintenance, repair, and general workshop use.

Spec Sheet:
