ITM Beam Beam Width
.
Regular price
$115.10 NZD
inc. GST
- Tested & certified to AS 4991
- 1000kg Rated capacity
- Violet colour coded to W.L.L. for safety
- Beam width to suit 75 - 230mm
- Weight: 3.6kg
- Dimensions (mm) A(max): 278 B (min): 182 B (max): 380 C: 64 D: 4 E: 217 F (min): 150 F (max):90 G: 26 H: 19
- Tested & certified to AS 4991
- 2000kg Rated capacity
- Green colour coded to W.L.L. for safety
- Beam width to suit 75 - 230mm
- Weight: 4.5kg
- Dimensions (mm) A(max): 278 B (min): 182 B (max): 380 C: 76 D: 6 E: 217 F (min): 150 F (max): 90 G: 25 H: 21
- Tested & certified to AS 4991 Specifications
- 10 000kg Rated capacity
- Orange colour coded to W.L.L. for safety
- Beam width to suit 90 - 320mm
- Weight: 15.9kg Dimensions (mm)
- A(max): 356
- B (min): 250
- B (max): 520
- C: 120
- D: 8
- E: 285
- F (min): 230
- F (max): 160
- G: 52
- H: 39
- Tested & certified to AS 4991 Specifications
- 3000kg Rated capacity
- Yellow colour coded to W.L.L. for safety
- Beam width to suit 80 - 320mm
- Weight: 9.1kg Dimensions (mm)
- A(max): 356
- B (min): 220
- B (max): 500
- C: 100
- D: 8
- E: 277
- F (min): 220
- F (max): 145
- G: 48
- H: 27
- Tested & certified to AS 4991
- 5000kg Rated capacity
- Red colour coded to W.L.L. for safety
- Beam width to suit 90 - 320mm
- Weight: 11.3kg
- Dimensions (mm) A(max): 356 B (min): 220 B (max): 500 C: 112 D: 8 E: 277 F (min): 220 F (max): 145 G: 45 H: 33
Dispatched within 24-48 hours.
Free shipping on $300+ orders. Exclusions may apply.
14-Day Return Policy.
Buy Now Pay Later available at checkout
Got questions? Feel free to get in touch.
Durable all steel construction
- Colour coded to WLL for safety
