Db Drive Amp X-Series 4ch Class D Rms 75w X 4 @ 4ohm / 150w X 4 @ 2 Ohm
Buy Now Pay Later available at checkout
Four-channel Class D amplifier for vehicle audio systems. Delivers 75W per channel at 4 ohms or 150W per channel at 2 ohms. Bridgeable for subwoofer duty. Suits installers upgrading factory or aftermarket car stereo setups in compact engine bays.
Specifications:
- Total dynamic power output – 600W
- Power output – 75W x 4 @ 4Ω stereo; 150W x 4 @ 2Ω stereo; 300W x 2 @ 4Ω bridged
- Frequency response – 20Hz–20kHz
- Gain level control – 0.2–6V
- Input impedance – 10kΩ
- Signal-to-noise ratio – 90dB
- High-pass filter – 30Hz–320Hz
- Low-pass filter – 30Hz–320Hz
- Variable bass boost – 0–12dB
- PCB – 4-layer
- Channels – 4
