Blackvue Dr770x-1Ch-Ii Front Facing Full Hd (1080) Dashcam 256 Gb

BlackVue DR770X-1CH II features Full HD Sony STARVIS™ image sensor for best image quality under any light.

Also included are GPS logger, built-in Wi-Fi, Cloud connectivity, impact and motion detection.

Full HD Cloud Dashcams

Powered by Sony STARVIS Sensors

Native Parking Mode

Let your BLACKVUE watch over your vehicle 24/7

What's Included?

• Front Camera
• Hardwiring Power Cable
• USB-C Power Cable
• USB-C 12V Adapter
• MicroSD Card
• Double-sided tape for the mounting bracket
• Pry tool / Trim Remover
• Cable clips (3 EA)
• Alcohol Pad

Specifications

Model Name DR770X-1CH II

Channel

1CH (upgradable to 2CH)

Highlights

Full HD, Cloud, Wi-Fi, GPS, Sony Sensor, External LTE Module

Product Dimensions

Black /length 135.0mm x Width 101.0mm x Height 37.5mm / 209g

Memory Support

microSD card up to 1TB

Recording Modes

Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).

• When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.

Parking Mode

YES (hardwiring cable included)

Parking Mode Event Voice Notifications

YES

Imaging Sensor

Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)

Viewing Angle

Diagonal 139°, Horizontal 116°, Vertical 62°

Resolution Frame Rate

Full HD @60fps

• Frame rate may vary during Wi-Fi streaming

Video Codec

H.264 (AVC)

Image Quality and Bitrate Front/Rear

• Highest (Extreme): 25 Mbps
• Highest: 12 Mbps
• High: 10 Mbps
• Normal: 8 Mbps

Format Free

YES (Adaptive)

Event File Overwrite Protection

YES (up to 50)

SD Card Failure Alert

YES

Scheduled Reboot

YES

Video File Extension

MP4

Wi-Fi

Built-in (802.11 b.g.n)

Cloud Compatible

YES

GPS

Built-in (Dual Band : GPS, GLONASS)

Specifications

Microphone

Built-in

Speaker

Built-in

Impact Sensor

3-Axis Acceleration Sensor

LED Indicators

Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED

Button

• Format Button: Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card.
• Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings.

Operation Temperature

• 20 °C − 80 °C (-4 °F − 176 °F)

Storage Temperature

• 20 °C − 80 °C (-4 °F − 176 °F )

High Temp Cut Off

Approx. 80 °C (176 °F)

Backup Battery

Built-in supercapacitor

Input Power

DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)

Power Consumption Hour

• Normal Mode (GPS On/1CH): Avg. 240mA / 12V
• Parking Mode (GPS Off/1CH): Avg. 190mA / 12V

• Actual power consumption may vary depending on use conditions and environment

Certifications

FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC

Software

BlackVue Viewer

• Windows 7 or higher, Mac Sierra OS X (10.12) or higher

BlackVue Web Viewer

• Chrome 71 or higher, Safari 13.0 or higher

Application

BlackVue Application

• Android 8.0 or higher, iOS 13.0 or higher

Others

Adaptive Format-Free File Management System

Bluetooth Built-in (V2.1+EDR/4.2)

LTE External (optional)
